Resolution: 203 dpi (8 dots per millimeter)
Memory: 512 MB SDRAM, 512 MB Flash
Maximum Print Width: 4.09 in. / 104 mm
Maximum Print Speed: 18 ips / 457 mm per second
Media Sensors: Transmissive and Reflective sensors
Maximum Continuous Print Length: 150 in. / 3801 mm
Minimum Label Length: —
Applicator Mode (Backfeed On): 0.50 in. / 12.7 mm
Applicator Mode (Backfeed Off): 0.25 in. / 6.4 mm
Stream Mode: 0.25 in. / 6.4 mm
Rewind Mode: 0.25 in. / 6.4 mm (“loose loop”)
Tear-off Mode (Backfeed On): 0.50 in. / 12.7 mm
Tear-off Mode (Backfeed Off): 0.25 in. / 6.4 mm
Label Width: 1 in. / 25.4 mm to 4.2 in. / 107 mm
Operating Temperature: 31°F to 104°F / 0°C to 40°C
Operating Humidity: 20% to 95% R.H. non-condensing
Storage / Transport Temperature: -40°F to 160°F / -40°C to 71°C
Storage Humidity: 5% to 95% R.H. non-condensing
Power Supply: Auto-ranging power supply with power factor correction, 90–264 VAC, 47–63 Hz
RFID: Field-installable UHF RFID kit available for 4-inch and 6-inch print widths
Bar Code Ratios: 2:1, 7:3, 5:2, and 3:1
1D Bar Codes: Code 11, Code 39, Code 93, Code 128 (subsets A/B/C and UCC Case Codes), ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC/EAN 2- or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar, and Planet Code
2D Bar Codes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, TLC 39, MicroPDF, RSS-14 (and composite), Aztec
Printing Technology: Thermal Transfer and Direct Thermal
Hand Orientation: Right-hand or Left-hand
Display: 4.3-inch color touch screen with intuitive menus for quick operation and setup
Construction: Industrial metal frame
Interfaces: USB 2.0, RS-232 Serial, Ethernet 10/100, Bluetooth 4.1, Dual USB Host, Applicator Interface
Clock: Real-time clock
