- General data:
Display screen: 5.7 inch TFT color touch screen
Working mains: AC 110V/220V，±10%，50/60Hz，±5% (default AC 220V 50Hz）
Fuse: 6A
Max. Power consumption: 200W
Memory space: Infinite（PC）
Communication mode: Ethernet, RJ45
Working indicator: LED, LCD front panel display
Size: 19 inch /4U
Weight: Approx. 23Kg
Temperature: 15–35℃
Humidity: 45%–75%
Air pressure range: 86kPa–106kPa
EFT/Burst test as per IEC 61000-4-4
- Burst module:
Test voltage: 0.25kV-4.8kV±10%
Polarity: +/-/alternative
Source impedance: 50 ohm
Pulse waveform: 5/50ns, 50 ohm 1000 ohm load
Rise time: 5ns±30%, 50 ohm load, 1000 ohm load
Pulse duration:
50ns±30%, 50 ohm load
50ns-15/+100ns, 1000 ohm load
Pulse frequency: 0.1kHZ-1000kHz
Burst duration: 0.075ms-750ms
Burst cycle: 11ms-9999ms
Test duration: 1s-9999s
Trigger mode: Automatic, manual or external
Synchronization: 0° - 360°, 1° step or random
Network attenuation ratio: <10% of setting voltage
Network:
EFT 500T built-in three phase CDN
AC 380V/16A; DC-1 220V/16A
