- Technical parameters:
Input mains: AC 220V 5KVA
Output waveform: Current waveform: 10（-10%﹢100%）μs/1000 (±10%）μs
Optional waveform: 8（±10%）/20（±10%）μs
Charging voltage: 0.2~2000V
Current peak: 3A～2000A
Output peak resolution: ±5%
Number of test : 1~99 adjustable
Interval time: 1~99s adjustable
Single recycle duration: 7s+ test duration
Control mode: Automatic continuous test or manual single test
DUT polarity judgment: Polarity can be identified automatically
- General data:
Power supply: AC220V ± 10%，50/60Hz
Temperature: 10-40℃，35%-85%RH（no condensation）
Dimension: 1200×700×1800mm
Weight: Approx. 500kg
- Technical parameters:
Surge pulse: IEC 61051-1
Rise time: 10μs-10%﹢100%
Duration: 1000μs±10%
First measurement range:
15A± 10% @1kV
30A± 10% @2kV
Second measurement range:
200A± 10% @1kV
400A± 10% @2kV
Third measurement range:
500A± 10% @1kV
1000A± 10% @2kV
Fourth measurement range:
100A± 10% @1kV
2000A± 10% @2kV
