- Technical Parameters:
Rated Voltage: 0 – 100 V, 0.1 V step
Voltage Dips / Surge Voltage: 0 – 100 V, 0.1 V step
Voltage Dips / Surge Time: 0.1 ms – 59.999 s
Voltage Rise / Fall Time: 0.1 ms – 10 s, adjustable (the min. depends on the test voltage)
Upper/Lower Overshoot of Output Voltage: < 10% of voltage variation (when load impedance of the generator is 100 Ω)
Time Interval: 0.1s – 60 s
Measuring Accuracy Current: 1% ± 0.1 A
Max Output Current (Steady State): See Optional Models
No. of Tests: 1 – 9,999
No. of Ripple: < 1% of rated output voltage
Over-Current Protection Mode: Set arbitrarily from 1A to max. value of current
Load Adjustment Rate: <5% (rate of change of the voltage with the load, 0 to rated current)
Output Impedance for Interruption: >100 kΩ
- General Parameters:
Display: 5.7” TFT touch screen
Operating Power Supply:
8U equipment: 220 V
50 / 60 Hz, ±10%
22U equipment: none
Auxiliary working power: AC 380 V
Fuse: 6 A (8U equipment)
Max Power: 300 W (main control part)
Dimension: 19”, 4 U x 2 pcs
WeightApprox: 40 kg
Operating Temp.: 15℃ - 35 ℃
Operating Humidity: 45% - 75%
Operating Air Pressure: 86 kPa – 106 kPa
