Pitch: 2.54 mm (0.1 in)
Wire Gauge: 28 AWG to 26 AWG
Application: Wire-to-Wire
Row Spacing: 2.54 mm (0.1 in)
Unit Weight: 2 kg
Housing Color: Gray
Latching Type: Ejector Latch
Contact Gender: Pin (Male)
Current Rating: 1 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Polyester
Termination Style: IDC
Mating Post Length: 6.1 mm (0.24 in)
Flammability Rating: UL 94 V-0
Number of Positions: 64 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 55 C
