Pitch: 2.54 mm (0.1 in)
Wire Gauge: 30 AWG to 26 AWG
Row Spacing: 2.54 mm (0.1 in)
Unit Weight: 11 g
Housing Color: Gray
Latching Type: Unlatched
Contact Gender: Pin (Male)
Current Rating: 1 A
Mounting Angle: Straight
Mounting Style: PCB Mount
Number of Rows: 2 Row
Contact Plating: Gold
Contact Material: Beryllium Copper
Housing Material: Polyester
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 64 Position
Insulation Resistance: 1 MOhms
Termination Post Length: 2.8 mm (0.11 in)
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 55 C
