DVB-C
Range: 46-870MHz
Modulation type: DVB-C/ITU-T J.83-Annex A
Support: 16/32/64/128/256 QAM
Power level: 30dBμV～110dBμV
Accuracy: ±2dB
L band width: Can be setted by users
Symbol rate: 1MS/S～8MS/S
MER: 22dB～40dB
MER Accuracy: ±2dB
BER: 10-4～10-8 Before R - S
Resolution: 10KHz ≤30ppm
Analog CATV
Power Level: 20dBμV～120dBμV
Accuracy: ±1.5dB
Impedance: 75Ω
Others
Power Supply: 7.2V 1600mAH rechargeable Li-ion battery, AC 90～240V 50/60Hz
Charging Time: 3 ~ 4 hrs
Working Time: > 6 hrs
Dimension: 180 x 82 x 40 (mm) x100x40(mm)
Weight: 0.32kgs (battery included)
Packing List: Main unit x1pcs, power adapter x1pcs, user manual x1pcs, certification report x1pcs, hybrid adapter x2pcs
