ABB 251 Paper Thickness Tester (0.0001 – 20.000 mm)

Range:

0.0001–20.000 mm

0.1–20 000 μm

0.001–750.0 mil

0.00001–0.7500 in

Indication error: ±1 μm or 0.1 % of reading whichever is greater

Instrument

Presentation: 8.4 in colour touch screen

Measuring system: Optical linear encoder

Max throat depth: 112 mm (4.4 in)

Test surface: Precision grained hardened stainless steel

Lowering speed: 0.2–3 mm/s (0.008–0.118 in/s)

Lifting speed: 5 mm/s (0.2 in/s)

Lifting height: Automatic adjustment of lifting height after the first measurement value in a series.

Dwell time: Adjustable 0–20 s

Repetitive measurement: Adjustable 0–10 s

Results

Measurement values:

- thickness (sheet or pad) in μm, mm, mil or inch

Statistics:

- mean value (sheet or pad)

- standard deviation

- coefficient of variation

- maximum and minimum values of the series

Connections

Data Ethernet

The instrument acts as a FTP-server.

Test results can be retrieved by a FTP-client.

Installation requirements

Power: 90W

Options:

Internal strip feeder

External thermal printer

Foot switch

Slip gauges

Strip holder (for guiding long strips)

Dimensions:

0.3 × 0.3 × 0.4 m

12 × 12 × 16 in

Volume: 0.12 m³/ 4.3 ft³

Net weight: 19 kg
