Gain: 1.3 dBi, 1.6 dBi, 3.1 dBi, 4.3 dBi
VSWR: 2
Width: 25.1 mm
Height: 8 mm
Length: 25.1 mm
Impedance: 50 Ohms
Application: Automotive, Geofencing, GNSS, IoT, Logistics, M2M, Navigation, Remote Monitoring, Surveying, V2X
Polarization: RHCP
Qualification: AEC-Q200
Mounting Style: PCB Mount
Electrical Type: Patch
Number of Bands: 5 Band
Center Frequency: 1.17645 GHz, 1.561098 GHz, 1.57542 GHz, 1.577 GHz, 1.602 GHz
Ground Plane Size: 70 mm x 70 mm
Maximum Frequency: 1.607 GHz
Minimum Frequency: 1.16445 GHz
Termination Style: Pin
Protocol - GPS, GLONASS: BEIDOU, Galileo, GLONASS, GNSS, GPS
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
