Hardware: ARM920T,400MHz
Comminication: Blue tooth、WIFI
Acquisition
Vibration:
Sensor：ICP Acceleration sensor
Integral: No integral, single integral, Double integral; Acceleration, velocity and displacement are collected simultaneously
Acquisition frequency: 100,200,500,lk,2k,5k,10k, 20k
Range :Acceleration：（A）（single peak）:0.1—199.9 m/s2
Velocity:（V）（True RMS）:0.1—199.9 mm/s
Displacement：（D）（Peak-Peak）:1—1999um
Error range：±5%
Electronic tags: Radio frequency card Electronic label
Radio frequency card Electronic label
Vibration signal analysis function
Statistical analysis: Kurtosis index; Waveform indicators; Margin index; Pulse index
Spectrum analysis: Side frequency Spectrum, Multiple frequency Spectrum
Waveform analysis: the cursor
Work model
Point inspection: Temporary task, new task, factory inspection, task management, result upload
Patrol Inspection: Management: RADIO frequency card
Power supply
Power: 3.7V Li-ion battery，Work continuously for 12 hours，3600mAh
Charge: USB
Work temperature: 0°C ~ 50°C
