Power Source: 12V Power adapter
Static Power Dissipation: 9W
Max Power Dissipation: 24W
Hardware Interface: USB 3.0
Number of Output Chs: 48
Memory Pattern Depth/ch: 256Mb/ch
Data Rate: 700Mbps (350MHz)
Internal Clock System Range: 1Hz ~ 2.4GHz (Period : 1s ~ 416ps)
Internal Clock System Resolution: 6 digits, Min. 1Hz
External Clock System Range: ≦ 200MHz
Threshold: -0.5V~4.5V@ 0.1V Resolution
Data Flow Control: Loop / Jump / Hold / Wait For Event
Clock / Channel Period Jitter: N/A
Internal Event: Hot Key
External Event Ch: 16
External Event Mode: Logic AND / Logic OR
External Event Threshold: -0.5V ~ 4.5V
Phase Tuning Delayed Time: Depend on Internal Clock, Min. 416ps
