Width: 50.8 mm
Height: 25.4 mm
Length: 76.2 mm
Industry: Industrial
Approvals: EN 62368-1
Dimensions: 76.2 mm x 50.8 mm x 25.4 mm
Output Power: 25 W
Input Voltage: 90 VAC to 264 VAC, 120 VDC to 370 VDC
Mounting Style: Through Hole
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 2 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 2.5 A
Output Current-Channel 2: - 2.5 A
Output Voltage-Channel 1: 5 V
Output Voltage-Channel 2: - 5 V
Operating Temperature Range: - 20 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
