Width: 23 mm
Height: 16 mm
Length: 32.5 mm
Industry: Industrial
Approvals: EN 62368-1
Dimensions: 32.5 mm x 23 mm x 16 mm
Output Power: 3 W
Input Voltage: 90 VAC to 264 VAC, 120 VDC to 370 VDC
Mounting Style: Through Hole
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 600 mA
Output Voltage-Channel 1: 5 V
Operating Temperature Range: - 20 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
