Specifications:
Maximum display: 199 999
Measurement speed (readings/s): 140 max
DC voltage measurement: 1 μV to 1000 V
Accuracy (typical value): 0.011%/year
DC current measurement: 1 μA to 10 A
Resistance measurement: 1 mΩ to 200 MΩ
AC voltage measurement (True RMS): 1 μV to 700 V
AC voltage frequency range: 20 Hz to 100 kHz
AC current measurement (True RMS): 1 μA to 10 A
Calculation function: ✓
Data memory: 20,000 (software version E00 or later)
Lineup:
USB: ✓
GPIB: -
RS232: ✓
External trigger input: ✓
Complete output: ✓
Comparator output: ✓
Supplied Accessories:
Power cable (JIS 2 m): 1
Input cable (test probe 1 m): 1
Power fuse (100/120 V): 1
Power fuse (220/240 V): 1 *Either one is included.
Overcurrent protection fuse: 1
