- Output Power: 2kW max at full rated output voltage and current
- Output Voltage: Units available with max output voltages from 10 ~ 300V
- Output Current Up to 100 A for 20 V and 6.5 A for 300 V
- Input Voltage: 185 ~ 255 VAC 47 ~ 63 Hz single phase plus protective earth, operation below 185 VAC is possible with linear power derating down to 1 kW at 85 VAC
- Input Current: Not exceeding 13 Arms (185 ~ 255 VAC). Harmonics are controlled with active power factor correction.
- Specification Range: Specifications apply above 5% of rated output voltage. The output can be controlled down to < 0.25% of rated output voltage.
- Output Ripple:
Voltage mode: < 0.1% peak to peak of rated output voltage 50 mV peak to peak
Current mode: < 0.2% peak to peak of rated output current 50 mA peak to peak
- Output Noise: < 300 mV up to 20 MHz
- Voltage Regulation:
Line: < 0.05% deviation in output voltage set point for a 10% change in supply line voltage
Load: < 0.1% deviation in output voltage set point for a 0 to 100% change in load current
- Current Regulation:
Line: < 0.1% deviation in output current set point for a 10% change in supply line voltage
Load: < 0.1% deviation in output current set point for a 0 to 100% change in output voltage
- Transient Response: Response for a 10 to 90% or 90 to 10% step change in load. Overshoot/undershoot < 2% of rated output.
Recovery to within 0.1% of rated output < 10 msec
- Temperature Coefficient: 100 ppm per °C (0.01% per °C)
- Drift: < 0.5% per 8 h after 1 h warmup
- Efficiency: > 85% at full output power
- Operating Temperature: 0 ~ 40°C (32 ~ 104°F)
- Storage Temperature: -20 ~ 70°C (-4 ~ 158°F)
- Humidity:
80% max relative humidity up to 31°C (88°F), reducing linearly to 50% at 40°C (104°F)
Non-condensing (ref BS EN61010-1)
- Altitude: Sea level to 2000 m (6500')
- Dimensions (W x D x H): 483 x 460 x 43.6 mm3 (19 x 18 x 1.72 in3)
- Weight: 6.6 kg (14.55 lb)
- Interface:
Analog, 15-way D-type connector
RS232 digital control
