Advanced Energy ThermAsset2 Fiber Optic Temperature Sensor (-30~200°C,90~265VAC/DC)

- Channels: 2, 4, 6, or 8
- Temperature Range: -30~200°C (-22 ~ 392°F)
- Accuracy: ± 2°C
- Input Power: Universal AC/DC [90~265VAC/DC]
- Analog Output: 4~20mA or 0~1mA
- Surge Protection: 3000V (IEEE C37.90.1-1989)
- Connectors: All ring-lug terminals
- Probes: Accepts all Luxtron Quality and DipTip rugged probes
- LED Alarm Indicators: One for each relay
- System Fault Status Indicator: 2 LEDs: green = OK, red = faulty condition
Environmental
- Operating Temperature Range: -40 ~ 70°C (-40 ~ 158°F)
- Storage Temperature Range: -30 ~ 75°C
Communication
- Serial Output: RS-232 and RS-485
- Protocol: Modbus and DNP3 options available
