Maximum test machine load: 2000N/ 200 kg/ 450 Lb
Minimum resolution: 0.1N/ 0.01kg/ 0.01Lb
Platen diameter: 108 mm
Measurable maximum free length of spring: 200mm
Displacement scale travel: 150mm
Dimensions: 790*610*320mm
Net weight: 67kg
Accuracy: ±1%
Power Supply: Alternating current 220V～50Hz
Operating temperature: 10℃～30℃
Storage temperature: -27℃～70℃
Relative humidity: 15%～80%RH
Features:
Chinese color screen display, better human-organization interface.
High precision and high resolution.
Three measurement units have their own switching: N (Newton), kg (Kilogram), Lb (British pound).
Gravity acceleration setting, higher measurement and conversion accuracy.
Store 99 sets of test data, which can be viewed, stored and deleted directly on the machine.
Print the stored measurement data and maximum, minimum and average values.
Communication function: It uses USB interface to communicate with PC. The synchronous test function can be connected to a computer for testing. The computer displays the test force curve and the detailed test force records during the test
