Min index value: 0.01
Max operating range (N.m): 60N.m / 44.25ft.lb / 531.04in.lb / 611.82kgf.cm
Connector(Inches): 3/8
Buzzer setting range(N.m): 1.8 ~ 60
Length(mm): 240
Accuracy*1: Clockwise:± 2% counterclockwise: ± 2%
Data storage capacity: 999
Operating mode: Peak mode (P)/ Real-time mode (T) / Preset mode (Pre)
Unit: N.m, kgf.cm,lbf.tf, lbf.in
Ratchet head form: Two-way ratchet head
Ratchet teeth: 72 teeth
Number of keys: 5
Operating temperature: -10 ℃ ~ 60 ℃
Storage temperature: -20 ℃ ~ 70 ℃
Drop test height: 1 meter
Vibration test conditions*2: 10G
Life span test* 3: 10000 times
* 1, the accuracy guarantee range is 20% to 100% of the MAX operating value. Torque accuracy is the normal value. The correction accuracy is based on the middle groove of the five grooves on the grip as the correction point. To ensure accuracy, it is recommended to calibrate once a year.
* 2. Life test includes horizontal test and vertical test.
* 3, \"Once \" means to apply a wrench from 0N.m to the MAX operation setting value of the wrench, and then return to 0N.m.
