Measuring Range M(n) (Nm): 5
Resolution (Nm): 0.005
Accuracy (% ): +/- 0.5 Class 1 (DKD-R 10-8)
Display range (% ): 120 of M(n)
Diplay Type : LCD. 5-digit. 29 mm high
Interface:
USB : USB 2.0 data communication and supply
Hirose: Limit/overload signals. digital I/O's
Software TTT_Certify: Quick check or creation of calibration certificates
Supply Type : Internal solar cell with storage capacitor / via USB
Temperature (operation) °C: 0...40
Housing:
L x W x H : 280 x 147 x 79
Weight (kg): 5
Fixing: On table top up to 30 mm thick by means of threaded bolt and knurled nut
Protection class (EN 60529) Cable not plugged : IP42 (protection against falling dripping water)
Operating mode:
Standard : Display of current value
Peak (click + max) : Peak value display (drag pointer function)
Quickcheck : Five follow-up measurements with averaging
Limit: Two separately selectable limits with upper and lower limit value
