Display: Triple 4 digit LCD Display
Auto power off: Approx. 3 minutes
Data memory capacity: 99 set. (Direct reading from LCD display)
Low battery indication:
Temperature: Operating: 0~40°C(32~104°F), Storage: -10~40°C(14~104°F)
Humidity: Operating: <85%RH., Storage: <70%RH.
Power source: 4x1.5 AAA (UM-4) Battery
Dimensions: Main unit: 140x70x31mm; Sensor : Φ44x55mm
Weight: 205g (not including battery)
Illuminating/ Viewing geometry: 45°/ 0°: Illumination at 45°, measrement at 0°
Illuminant: White LED lamp
Measuring area: Approx. Φ10mm
Display modes: Color difference: ∆(L*, a*, b*), ∆(E*ab, C*ab, H*ab), ∆(Y, x, y), ∆(X, Y, Z), ∆(Rs, Gs, Bs) or ∆(WI, YI, Tw)
Operating Temperature: Color space: (L*, a*, b*), (L*, C*ab, hab), (Y, x, y), (X, Y, Z), (Rs, Gs, Bs) or (WI, YI, Tw)
Target color memory: 9 channel; set by measurement or keypad
Measuring range: L*: 5 to 100
Measurement conditions: Observe: CIE 2° Standard Observer
RepeatabilIty: Standard deviation within ∆E*ab 0.5 (Measurement conditions: Average of measurements of standard white plate)
Measurements interval minimum: Approx. 2 seconds
Product Accessories
Standard Accessories:
Main Unit
Measuring head
White calibration card
Carrying Case
Operation Manual
Optional Accessories:
USB data output
