Parameters: Ra, Rz
Measurement Range:
Ra: 0.05~10.00μm / 1.000~400.0μinch
Rq: -
Rz: 0.020~100.0μm / 0.780~4000μinch
Rt: -
Accuracy: Not more than ±15%
Fluctuation of Display: Not more than 10%
Resolution:
0.001μm if reading < 10μm
0.01μm if 10μm ≤ reading < 100μm
0.1μm if reading ≥ 100μm
Evaluation Length: 1~2L Optional
Operation Temperature: 0~50°C (32~122°F)
Operation Humidity: <80%RH
Power Supply: 4×1.5V AA Um-3 Battery
Size: 128×80×30mm (5.0 × 3.1 × 1.2")
Weight (Including Battery): 270g (9.52oz)
