Specifications:
Indenter: Ball 5mmΦ
Convertible Probe: The curved end of the probe is used for the bobbin with a diameter less than or equal to 400mm, and the plane end of the probe is suitable for the bobbin with a diameter greater than 400mm
Area Of Application: For closely wound bobbins of synthetic fibers and closely wound natural fibers, yarns and threads
Display Range: 0~100H (hardness graduation marks)
Testing Range: 10~90H (hardness graduation marks)
Accuracy: ≤±1H
Resolution: 0.1H
Battery Indicator: Low Battery Indicator
Auto Switch Off: √
Depth Of Indentation*: 0~2.5mm
Test Pressure**: Approx. 12.5N
Measuring Spring Force*: 0.55~8.065N
Scale Diameter: 51mm
Working Face Radius: 55mm (when using the curved end of the probe)
Working Face Flat: 45mmΦ (when using the plane end of the probe)
Operating Temperature: 0~40°C
Operating Humidity: <80%RH
Power Supply: 2×1.5V AAA (UM-4) Battery
Size: 178×65×45 mm
Weight: 290 g (Not included Batteries)
Standard Accessories:
Main Unit
Carrying Case
Operation Manual
Optional Accessories:
USB Data Cable with Software
Bluetooth Data Adapter with Software
