Measurement Section
- Method: Contact method
- Range: Speed test: 0.1~2,000.0 m/min; Rotational speed test: 1~20,000 r/min; Distance test: 0~999m
- Note: Measurement is possible for up to 5,000mm. Measurement values of 999mm or larger can not be guaranteed.
- Accuracy: ±1count
- Time: 10ms
- Unit: m/min, r/min, mm
- Auto power-off: Turns OFF the power in 180 seconds after last operation.
- Value hold: Ch1 Value, CH2 Value, MAX Value
- Averaging: Performs averaging desired number of times (1 to 200 times)
- Memory function: Stores up to 20 sets of test results, larger amount of memory can be customized.
Detection Section
- Number of pulses: 400 pulses/rotation, slit reflection method
- Light source: Infrared LED
- Receive element: Photo diode
- Allowable: 5kg in radial direction, 5kg in thrust direction
- Bearing life: 2×10⁷ r/min·h (max. load within specification)
Display Section
- Display unit: 5-digit back light LCD (upper and lower)
- Update time: 100ms
- Resolution: 0.1 (m/min: Number of averagings above 10); 1 (r/min: Number of averagings above 10); 1 (mm)
Analog Output Section
- Contents: Instantaneous value (averaging result output)
- Voltage range: 0 to F.S. / 0 to 10 V
- Conversion mode: 10 bits D/A conversion
- Linearity: ±1% F.S.
- Update time: 10ms
- Output connector: Φ2.5 pin jack
Pulse Output Section
- Output method: Transistor output (open collector)
- Withstand voltage: 14V
- Number of pulses: 800/rotation
- Logic: Negative logic
- Pulse width: Approx 0.5 to 1.2µs
- Output connector: Φ2.5 pin jack
General Specifications
- Power supply: 2x3.7V 14500 lithium ion battery
- Operate temp.: 0~45°C
- Storage temp.: -10~60°C
- Operate humidity: 35~85%RH
- Storage humidity: 35~85%RH
- Dimensions: 211x80x36mm (8.3x3.1x1.4inch)
- Weight: 270g (Including batteries) 9.52oz
- Standard Accessories: Main Unit; Circumferential Ring; Power Adapter; 3.7V 14500 Lithium Ion Battery x2; Screwdriver; External Hold Signal Cable x2; Instruction Manual; Carrying Case
- Optional Accessories: Lengthening Rod for Rotating Contact Tip; Trigger Unit; Bluetooth Printer; USB Cable & Software; Bluetooth Adapter & Software
