Color: Black
Pitch: 4.2 mm (0.165 in)
Width: 40.5 mm
Gender: Receptacle (Female)
Height: 25.4 mm
Length: 28.5 mm
Application: Wire to Board/Device
Unit Weight: 16 g
Contact Gender: Without Socket Contacts
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 1 Row
Voltage Rating: 14 VDC
Wire Gauge Max: 17 AWG
Wire Gauge Min: 20 AWG
Contact Plating: Tin
Housing Material: Polyamide (PA)
Wire Gauge Range: 17 AWG to 20 AWG
Locking Mechanism: On the terminal
Termination Style: Crimp
Number of Positions: 6 Position
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
