Pitch: 4.5 mm (0.177 in)
Width: 47.55 mm
Gender: Plug (Male)
Height: 26.8 mm
Length: 28.6 mm
Material: Plastic
Application: Wire to Wire
Row Spacing: 6.8 mm
Unit Weight: 17 g
Contact Type: Receptacle
REACH - SVHC: Details
Contact Gender: Without Pin Contacts
Current Rating: 13 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Voltage Rating: 250 VDC
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polybutylene Terephthalate (PBT)
Wire Gauge Range: 14 AWG to 20 AWG
Locking Mechanism: N/A
Termination Style: Crimp
Ingress Protection: IP67
Number of Positions: 8 Position
Attachment Hole Diameter: 1.6 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
