Color: Black
Pitch: 2.5 mm (0.098 in)
Width: 33.7 mm
Gender: Receptacle (Female)
Height: 19.2 mm
Length: 32.8 mm
Application: Wire to Wire
Row Spacing: 4.5 mm
Unit Weight: 8.200 g
Contact Gender: Without Pin Contacts
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Voltage Rating: 12 VDC
Wire Gauge Max: 20 AWG
Wire Gauge Min: 22 AWG
Contact Plating: Tin
Housing Material: Polybutylene Terephthalate (PBT)
Wire Gauge Range: 22 AWG to 20 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Number of Positions: 20 Position
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 30 C
