Gain: 1.4 dBi
VSWR: 3:1
Style: Blade Tilt / Swivel
Width: 20.1 mm
Length: 135.7 mm
Impedance: 50 Ohms
Application: Cellular Application, Satellite Application, Wireless Application
Polarization: Linear
Power Rating: 10 W
Mounting Style: Panel Mount
Number of Bands: 6 Band
Center Frequency: 657 MHz, 700 MHz, 750 MHz, 800 MHz, 850 MHz, 900 MHz, 1474 MHz, 1561 MHz, 1575 MHz, 1602 MHz, 3400 MHz, 3500 MHz, 3600 MHz, 4500 MHz, 4900 MHz, 5200 MHz, 5500 MHz, 5800 MHz
Mechanical Style: Whip
Maximum Frequency: 5.925 GHz
Minimum Frequency: 617 MHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Antenna Connector Type: SMA Male
Protocol - GPS, GLONASS: BEIDOU, Galileo, GLONASS, GPS
Protocol - WiFi - 802.11: 802.11, WLAN, WiFi
Maximum Operating Temperature: + 65 C
Minimum Operating Temperature: - 20 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, WCDMA, HSPA, EDGE, GPRS
