Width: 18.7 mm
Height: 30.2 mm
Length: 29.6 mm
Coil Type: Non-Latching
Compliance: UR, CSA
Unit Weight: 36.288 g
Coil Voltage: 12 VDC
Contact Form: DPDT (2 Form C)
REACH - SVHC: Details
Mounting Style: Through Hole
Coil Resistance: 2.5 kOhms
Coil Termination: Solder Pin
Contact Material: Silver (Ag)
Power Consumption: 20 mW
Switching Voltage: 120 VAC
Relay Contact Form: 2 Form C (DPDT-NO, NC)
Contact Termination: Solder Pin
Contact Current Rating: 3 A
