Color: Black
Pitch: 4.5 mm (0.177 in)
Width: 47.6 mm
Gender: Plug (Male)
Height: 21.45 mm
Length: 30.2 mm
Application: Wire to Wire
Row Spacing: 2.54 mm
Unit Weight: 13.162 g
Contact Gender: Without Pin Contacts
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Voltage Rating: 16 VDC
Wire Gauge Max: 15 AWG
Wire Gauge Min: 22 AWG
Housing Material: Polybutylene Terephthalate (PBT)
Wire Gauge Range: 15 AWG to 22 AWG
Locking Mechanism: On the terminal
Termination Style: Crimp
Ingress Protection: IP69K
Number of Positions: 10 Position
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 40 C
