Pitch: 7.92 mm (0.312 in)
Application: Wire-to-Board
Unit Weight: 600 mg
Housing Color: Natural
Contact Gender: Pin (Male)
Current Rating: 7.5 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 1 Row
Voltage Rating: 250 V
Contact Plating: Tin
Contact Material: Brass
Housing Material: Polybutylene Terephthalate (PBT)
Termination Style: Solder Pin
Mating Post Length: 7.7 mm (0.303 in)
Flammability Rating: UL 94 V-0
Number of Positions: 3 Position
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 25 C
