Pitch: 2.54 mm (0.1 in)
Application: Board-to-Board
Current Rating: 3 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Contact Plating: Gold
Contact Material: Phosphor Bronze
Housing Material: Thermoplastic (TP)
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 12 Position
Insulation Resistance: 5 GOhms
Termination Post Length: 2.41 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 65 C
