Pitch: 2.54 mm (0.1 in)
Application: Board-to-Board
Unit Weight: 3.009 g
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 3 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Voltage Rating: 1 kV
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Thermoplastic (TP)
Termination Style: Solder Pin
Mating Post Length: 6 mm (0.236 in)
Number of Positions: 10 Position
Insulation Resistance: 1 GOhms
Termination Post Length: 4.96 mm (0.195 in)
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
