Gender: Jack (Socket)
Polarity: Standard
Impedance: 50 Ohms
Isolation: Non-Isolated
RF Series: N Type
Body Style: Bulkhead
Body Finish: Nickel
Orientation: Straight
Unit Weight: 42.180 g
REACH - SVHC: Details
Body Material: Brass
Mating Cycles: 500
Mounting Style: Bulkhead - Front Mount
Voltage Rating: 7 kV
Contact Plating: Silver
Contact Material: Beryllium Copper
Maximum Frequency: 11 GHz
Termination Style: Solder Cup
Coupling Mechanism: Threaded
Contact Termination: Solder
Insulation Resistance: 5 GOhms
Maximum Operating Temperature: + 200 C
Minimum Operating Temperature: - 65 C
