Gender: Jack (Socket)
Polarity: Standard
Impedance: 50 Ohms
Isolation: Non-Isolated
RF Series: SMB
Body Style: Straight
Body Finish: Gold
Orientation: Straight
Unit Weight: 2 g
REACH - SVHC: Details
Body Material: Zinc Die Cast
Mating Cycles: 500
Mounting Style: Through Hole
Voltage Rating: 335 V
Contact Plating: Gold
Contact Material: Brass
Maximum Frequency: 4 GHz
Termination Style: Solder Pin
Coupling Mechanism: Slide On
Contact Termination: Solder
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 165 C
Minimum Operating Temperature: - 65 C
