Gender: Jack (Socket)
Polarity: Standard
Impedance: 75 Ohms
RF Series: MCX
Body Style: Vertical PCB Mount
Body Finish: Gold
Orientation: Straight
Unit Weight: 2.529 g
REACH - SVHC: Details
Body Material: Brass
Mating Cycles: 500 Cycle
Mounting Style: Edge Launch
Board Thickness: 1.574 mm
Contact Plating: Gold
Contact Material: Beryllium Copper
Maximum Frequency: 12 GHz
Termination Style: Solder
Coupling Mechanism: Push On
Contact Termination: Solder
Maximum Operating Temperature: + 165 C
Minimum Operating Temperature: - 65 C
