Gain: 3.5 dBi, 3.8 dBi, 4.8 dBi, 28 dB, 31.5 dBi, 31.8 dBi, 32.8 dBi
Height: 48 mm
IP Rating: IP67
Impedance: 50 Ohms
Application: Asset Tracking, BDS, Fleet Management, Galileo, GPS, GLONASS, Location Based Services, Military and Security, Navigation Devices, Network Synchronization and Timing, QZSS
Mounting Style: Screw Mount
Number of Bands: 3 Band
Center Frequency: 1.561 GHz, 1.57542 GHz, 1.602 GHz
Mechanical Style: Dome
Maximum Frequency: 1.606 GHz
Minimum Frequency: 1.56 GHz
Termination Style: Connector
Antenna Connector Type: N-Type (Jack)
Protocol - GPS, GLONASS: BDS, Galileo, GLONASS, GPS, QZSS
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
