Color: Black
Gender: Plug (RP - Female)
Length: 30.1 mm
Insulation: Insulated
Unit Weight: 7.492 g
Contact Type: Socket
Mating Gender: Receptacle
Contact Gender: Without Socket Contacts
Current Rating: 13 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 14 AWG to 20 AWG
Ingress Protection: IP67
Mating Part Number: AT04-3P
Flammability Rating: UL 94 V-0
Number of Positions: 3 Position
Description/Function: Contacts Sold Separately
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
