AC voltage (True-rms): 0 to 1000.0 V; ±0.8% + 5LSD (50 to 60 Hz)
DC voltage: 0 to 600.0 V; ±1.0% + 5LSD
AC+DC voltage: 0 to 1000.0 V
±1.0% + 7LSD (50 to 60 Hz)
±1.8% + 7LSD (DC 40 to 200 Hz)
±1.2% + 7LSD 200 to 400 Hz)
AC current: 0 to 600.0 A
±1.8% + 5LSD (50 to 60 Hz)
±2.0% + 5LSD (100 to 400 Hz)
DC current: 0 to 1000.0 A; ±1.8% + 5LSD (DC 50 to 100 Hz)
0 to 1000.0 A
AC+DC current: 0 to 1000.0 A
±2.2% + 7LSD (40 to 100 Hz)
±2.5% + 7LSD (100 to 400 Hz)
Precise low current AC: 0 to 60.00 A
±1.5% + 5LSD (50 to 60 Hz)
±2.0% + 5LSD (0.00 to 20.00 A, 100 to 400 Hz)
±3.0% + 5LSD (>20.00 to 60.00 A, 40 to 100 Hz)
±3.0% + 5LSD (>20.00 to 60.00 A, 100 to 100 Hz)
Precise low current DC: 0 to 60.00 A
±1.5% + 5LSD (0.00 to 20.00 A)
±3.0% + 5LSD (>20.00 to 60.00 A)
Frequency: 5.00 to 999.9 Hz; ±1.0% + 5LSD (600 V range)
50.0 to 400.0 Hz; ±2.0% + 4LSD (600 A range)
0.0 to 60.00 kΩ
Resistance: ±1.0% + 5LSD
Capacitance: 0.0 to 2500 µF; ±2.0% + 4LSD; ON ≤ 10 Ω; Off > 250 Ω
Continuity beeper: ON ≤ 10 Ω; Off > 250 Ω
Temperature: -40.0 to 752 °F
-40.0 to 400 °C
±1.0% + 3.0 °F (-40.0 to 14.0 °F)
±1.0% + 1.5 °F (>40.0 to 99.9 °F)
±1.0% + 2.0 °F (100 to 752 °F)
±1.0% + 1.5 °C (-40.0 to 10.0 °C)
±1.0% + 0.8 °C (>-10.0 to 99.9 °C)
±1.0% + 1.0 °C (100 to 400 °C)
Non-contact voltage: 10 V to 1000 V AC (50 to 60 Hz)
Phase rotation indication: Rotation-R for main supply ; Rotation-M for motors
Jaw opening:2.0 in (51 mm)
Safty rating CAT IV 600V ; CAT III 1000 V
Included Accessories: Banana Plug Type-K Thermocouple, Test Leads, Alligator Clip Set, (2) AAA Batteries (installed), User Manual, Carrying Case
