Range: 2 Ω
Nominal Current: 5 mA
Failsafe Current: 8 mA
Resolution: 100 uΩ
Accuracy: ± .02% of reading & ± .05% of range
Range: 20 Ω
Nominal Current: 5 mA
Failsafe Current: 8 mA
Resolution: 1 mΩ
Accuracy: ± .02% of reading & range
Range: 200K Ω
Nominal Current: 0.5 uA
Failsafe Current: 8 mA
Resolution: 10 Ω
Accuracy: ± .05% of reading & range
Range: 20M Ω
Nominal Current: 0.05 uA
Failsafe Current: 8 mA
Resolution: 1 KΩ
Accuracy: ± 2% of reading & ± 0.2% of range
Display: 4 1/2 digit LED
Terminals: Banana jack binding posts
Storage Temperature Range: -10° to 70° C
Operating Temperature Range: 0° to 50° C
Dimensions: 9.75″ x 10″ x 3.25″
Weight: 3 lbs.
Power: 4 ea rechargeable 5AHr NICAD batteries
Max. Input Voltage: 250 VDC
Open Circuit: 1.6 VDC
Max. Internal Voltage: 4.8 VDC
Update: 3 readings/second
Temperature Coefficient: ± 0.1 x accuracy per 1° C
