Range: 20 mΩ
Nominal Current: 1 A
Resolution: .001 mΩ
Accuracy: ± .025% of range
Range: 200 mΩ
Nominal Current: 100 mA
Resolution: .01 mΩ
Accuracy: ± .025% of range
Range: 2 Ω
Nominal Current: 100 mA
Resolution: .1 mΩ
Accuracy: ± .025% of range
Range: 20 Ω
Nominal Current: 10 mA
Resolution: 1 mΩ
Accuracy: ± .025% of range
Terminal: Trident
Display: 4 1/2 digit LCD
Update: 1 reading per 3 seconds
Power: Internal rechargeable battery pack
Weight: 3 lbs.
Dimensions: 7.69″ x 7.56″ x 3″
Max. Internal Voltage: 5 VDC
Open Circuit: ~5 VDC
Operating Temperature Range: -20° to 50° C
Storage Temperature Range: -40° to 75° C
Temperature Coefficient: ± .0025% per 1° C
Max. Input Voltage: 250 VDC
