Width: 9.4 mm (Max)
Height: 4.7 mm (Max)
Length: 9.4 mm (Max)
Shutdown: No Shutdown
Technology: BiFET
Supply Type: Dual
Unit Weight: 7.792 g
Amplifier Type: General Purpose Amplifier
Mounting Style: Through Hole
SR - Slew Rate: 10 V/us
Voltage Gain dB: 80 dB
Number of Channels: 1 Channel
Dual Supply Voltage: +/- 9 V, +/- 12 V, +/- 15 V, +/- 18 V
Supply Voltage - Max: +/- 20 V
Supply Voltage - Min: +/- 5 V
Pd - Power Dissipation: 330 mW
Ib - Input Bias Current: 300 pA
Operating Supply Current: 7 mA
Output Current per Channel: 50 mA
Vos - Input Offset Voltage: 2 mV
Maximum Dual Supply Voltage: +/- 20 V
Minimum Dual Supply Voltage: +/- 5 V
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
CMRR - Common Mode Rejection Ratio: 85 dB
PSRR - Power Supply Rejection Ratio: 85 dB
