Gain: 9 dB
Technology: Si
IF Frequency: 1 MHz to 900 MHz
LO Frequency: 500 MHz to 8 GHz
RF Frequency: 1.5 GHz to 7 GHz
Mounting Style: SMD/SMT
NF - Noise Figure: 23.9 dB
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 3 V
Operating Supply Current: 192 mA
Operating Supply Voltage: 3.3 V
P1dB - Compression Point: 11.3 dBm
OIP3 - Third Order Intercept: 31 dBm
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
