Shutdown: Shutdown
Unit Weight: 14.786 mg
3 dB Bandwidth: 2 GHz
Amplifier Type: High Speed
Mounting Style: SMD/SMT
SR - Slew Rate: 3.3 kV/us
Voltage Gain dB: 65 dB
NF - Noise Figure: 6.9 dB
Number of Channels: 1 Channel
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 2.7 V
Ib - Input Bias Current: 62 uA
Maximum Input Resistance: 165 kOhms
Operating Supply Current: 52 mA
Ios - Input Offset Current: 10 uA
Output Current per Channel: 95 mA
Vos - Input Offset Voltage: 300 uV
GBP - Gain Bandwidth Product: 10 GHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 8.8 pA/sqrt Hz
en - Input Voltage Noise Density: 1.1 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 90 dB
PSRR - Power Supply Rejection Ratio: 85 dB
