Measuring range: :
- Beer products: 0 to 12 % v/v
- Wine products: 0 to 20 %v/v
- Sake products: 0 to 20 %v/v
- Whiskey products : 35 to 65 %v/v
- Cognac products: 0 to 65% v/v
- Vinegar products: -
ypical deviation to distillation (all products): < 0.1%v/v
Repeatability s.d.: 0.03 %v/v
Temperature
Displayed temperature 1): 15 °C or 20 °C (59 °F or 68 °F)
Repeatability s.d.: 0.01 °C (0.018 °F)
Sample temperature: 18 to 25 °C (64.4 °F to 77 °F)
Typical measuring time: 1 to 3.5 min
Sample volume: 20 mL (syringe filling) vs. 40 mL (sampler filling)
Data memory: Measurement data: up to 10,000
Check results: up to 300
Adjustment results: up to 300
Products: up to 40
Custom quantities: up to 50
Images: up to 50
Display: 10.1" TFT WXGA (1280x800 px); PCAP touchscreen
Controls: Touchscreen, optional keyboard, mouse, and barcode reader
Interfaces: 4 x USB 2.0 (type A)3), 1 x USB OTG (Micro-A), 1 x RS-232, 1 x Ethernet (100 Mbit), 1 x CAN Bus
Voltage: 100 to 240 V~, 50/60 Hz, fluctuation ±10 %
Power consumption: 90 VA
Dimensions (L x W x H): 526 mm x 347 mm x 230 mm (20.7 in x 13.7 in x 9 in)
Weight: 17.6 kg
