Range
Extract: 0 °Plato to 30 °Plato
Alcohol: 0 %v/v to 10 %v/v
Parameters:
Original extract [°Plato]
Apparent extract density [°Plato]
Alcohol [%w/w]
Alcohol 20 °C [%v/v]
Real extract [°Plato]
Real degree of fermentation [%]
Fermentation speed [Alcohol 20 °C increase in %v/v per hour]
Temperature control method: Automatic temperature compensation; integrated Pt-100
Ambient temperature range: -20 °C to 60 °C
Process temperature: -20 °C to 100 °C
CIP/SIP up to 145 °C for 30 min
Pressure range, absolute: 100 mbar to 16 bar (10 bar @ >120 °C)
Weight: approx. 7 kg
Process wetted parts, standard: Stainless steel 1.4404
PEEK
Sapphire (Al2O3 – 99.997 %)
Enclosure protection: IP65; IP67 / NEMA 6P
Communication:
Analog
Analog/Digital
HART
Modbus RTU
Modbus TCP
PROFIBUS DP
PROFINET IO
EtherNet/IP
Process connections: Tuchenhagen VARIVENT® Type N
