Bearing design : Air, fine-pored carbon
Motor design: Electronically commutated (EC) – permanent magnet synchronous motor
Displacement transducer: High-resolution optical encoder
Minimum torque (rotation): 0.4 μNm:
Minimum torque (oscillation): 0.4 μNm:
Maximum torque: 125 mNm: 215 mNm
Minimum angular deflection (set value): 1 μrad
Maximum angular deflection (set value): ∞ μrad
Maximum speed: 1,500 rpm
Minimum angular frequency1): 2 x 10⁻⁵ Hz
Maximum angular frequency: 100 Hz
Temperature oven design: Electrical temperature oven
Recommended measuring geometry: Plate-plate, disposables: Plate-plate, cone-plate, disposables
Temperature range: -150 °C to +400 °C
Maximum heating rate: 50 °C/min
Maximum cooling rate: Up to 100 °C/min²)
Dimension (W x H x D): 380 mm x 660 mm x 530 mm
Weight: 33 kg
