Input voltage: DC 24V
Input Current: < 600mA
Power: 10W
Output voltage: ±5000V-±6500V
Ion emission: Pulse AC
Emitter electrode: Tungsten alloy
Discharge structure: Resistance coupling
Output frequency: 5,10,30,55,105Hz; (factory setting: 55Hz)
Duty factor: 5%—95%
Discharge range: L*W*H:{275-2975(Needle spacing 50mm)}*300*1000mm
Installation distance: 100→1000mm
Ion balance: ≤|±30V|(AVG)
Discharge speed: ≤2S
Condition monitoring: RS485 communication (can be connected in series for network monitoring)
Air pressure: ≤0.6MPa
Compressed air connector: Φ8-G1/8 grey
Media used: Clean compressed air
Working temperature: 0℃-50℃
Working humidity: < 70%
Dimensions: L*W*H:{275-2975(Needle spacing 50mm)}*36*68.2mm
Bar material: Flame retardant PVC,ABS,SUS,W
Packaging accessories: 180°rotatable mounting angle
Power supply : GRT-240200: DC24V 2A, dual network port output, 123*61*40.5mm (L*W*H)
Power cord: 2.5m
