Resolution (H x V Pixels): 5496 x 3672 (full resolution)/ 5472 x 3648 (default resolution)
Resolution: 20 MP
Sensor Type: Sony IMX183CQJ-J Progressive scan CMOS
Sensor Format: 1 inch
Effective Sensor Diagonal: 15.86 mm
Pixel Size (H x V): 2.40 x 2.40 μm
Frame Rate (at Default Settings): 17 fps, 53 fps (with sensor binning)
Mono / Color: Color
Image Data Interface: USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Synchronization: Via hardware trigger, Via software trigger, Via free run
Exposure Time Control: Via hardware trigger, Programmable via the camera API
Camera Power Requirements: ≈3.1 W (typical) @ 5 VDC (minimum 4.5 VDC)
Lens Mount: C-mount
Size (ø x L): 29.3 x 29 x 29 mm (without lens mount or connectors) 48.2 x 29 x 29 mm (with lens mount and connectors)
Weight: <80 g
Conformity: CE (includes RoHS), UL Listed, FCC Class B, GenICam 2.x (including PFNC 2.x and SFNC 2.x), IP30, USB3 Vision, ISO 13485:2016, REACH, KC
Software: Basler pylon Camera Software Suite (version 4.0 or higher) Available for Windows, Linux x86, Linux ARM, macOS, and Android
