Display mode: 4.3-inch TFT color screen
Measuring speed:
- Fast: 30 times/sec
- Slow: 8 times/sec
Test side configuration: Four-terminal measurement
Trigger mode: Internal/ External/ Manual/Contact
Clear mode: Self-stabilizing, free of zero (can be cleared when needed)
Measuring range: 1uΩ~2MΩ
Test accuracy: ≤20mΩ 0.2%
20mΩ-200kΩ 0.05%
200kΩ-2MΩ 0.2%
Range: 9 range automatic and manual
Temperature measurement: -55°C~+125°C
Temperature compensation: 20°C/25°C switchable
Setting method: Absolute value upper/lower limit; percentage upper/lower limit + nominal value
Delay: 0-999ms can be set
Standard interface: RS232C, HANDLER, USB HOST
U disk data storage: Available
Size: 216mm(width)*90mm(height)*330mm(length)
Weight: about 3.6kg
Power requirement: 198VAC~242VAC 47Hz~63Hz
