Rated value:
- Input voltage: 0~360V
- Input current: 1mA~30A
- Input power: 150W
Display mode: LED with backlight
Range/ Accuracy/ Resolving Power
Load accuracy: 0-36V/ ±(0.1%+0.03%FS)/ 1mV
0-360V/ ±(0.1%+0.03%FS)/ 10mV
0-3A/ ±(0.1%+0.1%FS)/ 1mA
0-30A/ ±(0.2%+0.3%FS)/ 10mA
Fixed voltage mode: 1.5V-36V/ ±(0.1%+0.03%FS)/ 1mV
1.5V-360V/ ±(0.1%+0.03%FS)/ 10mV
Fixed current mode: 0-3A/ ±(0.1%+0.1%FS)/ 1mA
0-30A/ ±(0.2%+0.3%FS)/ 10mA
Fixed resistance mode: 0.1Ω-10Ω/ ±(1%+0.3%FS)/ 0.001Ω
10Ω-99Ω/ ±(1%+0.3%FS)/ 0.01Ω
100Ω-999Ω/ ±(1%+0.3%FS)/ 0.1Ω
1KΩ-4KΩ/ ±(1%+0.8%FS)/ 1Ω
Fixed power mode: 0-10W/ ±(1%+0.1%FS)/ 1mW
10-100W/ ±(1%+0.1%FS)/ 10mW
100-300W/ ±(1%+0.1%FS)/ 0.1W
Current measurements: 0-3A/ ±(0.1%+0.1%FS)/ 1mA
0-15A/30A/ ±(0.2%+0.3%FS)/ 10mA
Voltage measurements: 1.5V-36V/ ±(0.1%+0.03%FS)/ 1mV
1.5V-360V/ ±(0.1%+0.03%FS)/ 10mV
Battery test function
- Input voltage: 0.8-360V
- Maximum capacity: 999A/H
- Resolving power: 10mA
- Discharge time: 1~60000sec
Dynamic test mode:
- T1&T2(A or B Value Test Time): 1mS-999S
- Error<3% + 1mS
Protection scope: >Rated condition 5%
Input impedance: ≥200KΩ
Outline size: W*H*D 225mm*100mm*330mm
Weight: About 5.5Kg
